GFUVE GF112D

PRICE: Call

GF112D is a single-phase handheld electronic meter test unit in accuracy class 0.05, 0.1 or 0.2, used for testing single phase electricity meters error on site. Wide measurement range from 1mA to 120A and 0 to 600V, and also can be used to test alternating current parameters-voltage, current, active power, reactive power, apparent power, harmonics, phase angle, power factor, frequency, energy etc.



FUNCTIONS

■ 4-quadrant measurement;

■ Vector diagram display;

■ Rotary field indication;

■ External thermal-printer;

■ Display of vector diagram;

■ Energy meter counters testing;

■ Data logger for all the parameters;

■ Testing of energy and power registers;

■ Testing of 1P2W electricity meter error;

■ Testing of 1P2W inductive energy meter error;

■ Testing of 1P2W mechanical energy meter error;

■ Frequency, phase angle and power factor measurement;

■ Oscilloscope function display current & current wave;

■ Harmonic analysis for voltage and current up to the 63th harmonics;

■ Power and energy measurement of active, reactive and apparent energy;



FEATURES

■ Smart optical sampler;

■ 3.5 inch color touch TFT LCD;

■ Accuracy class 0.05, 0.1, 0.2;

■ Easy and user friendly operation;

■ Lithium batteries can be replaced;

■ Storage 20000 groups calibrate data;

■ With PC software, export test report;

■ The best light weight meter test set;

■ With bluetooth & USB communication port;

■ Wide measuring range 0-600V/0.001-120A;

■ Automatic compensation for current clamp;

■ ISO17025 standard, with CNAS certificate;

■ Unique long-term and temperature stability;

■ The Li-battery can work 48 hours continuously;

■ One screen displays all the measured parameters;

■ The meter and current clamp have integration design.
